The feed enters the primary crushing chamber and meets the breaker bars which impel the feed against the front breaker plate. This action and the collision of material against new feed results in impact reduction. Material is sufficiently reduced in the primary chamber and passed by the front breaker plate, entering the secondary chamber for final reduction. Breaker plates are shaft suspended at the front and from a spindle in the rear, allowing for continuous gap adjustment as wear progresses and assuring superior product control.
1 High reduction ratios up to 30:1
2 Cubical gravel crusher with high crush count.
3 Selective crushing by speed and breaker plate adjustment
4 Interchangeable wear parts
5 Capacities from 5 to 1,600 TPH
6 Available with front or rear opening housings
7 Feed sizes up to 16”
8 One-man changeout of breaker bars
Model |
Specification(mm) |
Feed size(mm) |
Max feed size(mm) |
Capacity(t/h) |
Motor power(kw) |
Weight(t) |
PF1010 |
Φ1000×1050 |
400X1080 |
350 |
50-80 |
75 |
12.5 |
PF1210 |
Φ1250X1050 |
400X1080 |
350 |
70-130 |
110 |
16.5 |
PF1214 |
Φ1250X1400 |
400X1430 |
350 |
90-180 |
132 |
19 |
PF1315 |
Φ1320X1500 |
860X1520 |
500 |
120-250 |
200 |
24 |
PF1320 |
Φ1320X2000 |
860X2030 |
500 |
160-350 |
260 |
27 |
