Ascend small lab sample mill pulverizer mill grinding powder

Short Description:

Ascend sample pulverizer mill is working for trail plant, it has small capacity and can crushing the materialwith high efficiency. The working system way is vibrating grinding type. The material will load into the bowl, there is crushing ring and crushing hammer inside, in high speed rotation way the bowl will have vibrating and grinding function, will crushed to 80-200 mesh sample size by crushing ring and crushing hammer in 2-6 mintues, make it for testing directly.

Send email to us

Product Detail

Product Tags

Production video

Performance advantage

(1) High efficient no need screening again, the output material could be used for testing directly.
(2)Digital timing screen, special designed high quality motor, with long service life.
(3)Sealed grinding pot, dust proof, no pollution.
(4) Low noise, smooth operating, complete sealed machine, with high safety operation standard.
(5) Reliable, evenly output size, short grinding time.
(6) Simple and reasonable structure, good out look, easy to operate, maintenance, and clean.

Specification

Model	GJ-1	GJ-2	GJ-3	GJ-4	GJ-5	GJ-6
Disc dia.(mm)	150	175	200	250	280	300
Feed size(mm)	≤13	≤13	≤13	≤13	≤13	≤13
Discharge size(mesh)	80-200	80-200	80-200	80-200	80-200	80-200
Capacity(gram/batch)	100	100x2	100x3	100x4	100X5	100X6
Power(KW)	1.1	1.1	1.5	1.5	2.2	2.2
Voltage	380V50HZ	380V 50Hz	380V 50Hz	380V50Hz	380V50Hz	380V50Hz
Weight/KG	100	120	150	170	220	240
