Main parts of wet pan mill are frame, basin, grinding rller, grinding base, speed reducer,motor and etc. When the wet pan mill starts working, firsliy, motor transmits power to speed reducer. then center driving shaft transmits into horizontal shaft. fnally grinding roller will move countercockwise and material will be ground into fine particle in the wet panmill.
Model |
Type(mm) |
Max. feed size(mm) |
Capacity (t/h) |
Power(kw) |
Weight(t) |
1600 |
1600x350x200x460±20 |
<25 |
3-5 |
Y6L-30 |
13.5 |
1500 |
1500x300x150x420±20 |
<25 |
2.5-3.5 |
Y6L-22 |
11.3 |
1400 |
1400x250x150x350±20 |
<25 |
1.2-2.8 |
Y6L-18.5 |
8.5 |
1200 |
1200x180x120x250±20 |
<25 |
0.25-0.5 |
Y6L-7.5 |
5.5 |
1100 |
1100x160x120x250±20 |
<25 |
0.15-0.25 |
Y6L-5.5 |
4.5 |
1000 |
1000x180x120x250±20 |
<25 |
0.15-0.2 |
Y6L-5.5 |
4.3 |
